M5600045
Case Feet Kit 2
Universal case feet with tilt legs for all types of plastic and metal enclosures with max. 0.016" (4 mm) wall thickness.
Tilt legs:
F Max. 200 N (TÜV SÜD tested: ASTM D642-00 - compression test)
Topple load 3.69 kg (TÜV SÜD tested: DEF STAN 00-35 Part 4 Issue 3 - topple test)
Call us for a free sample.
With tilt legs.
Supply
Foot molding (x4), tilt leg (x2), TPE non-slip insert (x4), self-tapping screw (x4).
Generate Your PDF Datasheet for M5600045
Please select the product details you would like to include in the PDF.
M4919115
Supply 1U x 19" front panel, two handles, top cover, base panel, rear panel, M3 x 8 mm (x6), M3 x 8 mm (x4), M4 nut and washer (x4). Supplied assembled.
M4919115
VERSAMET 19" 1Ux6.49"Light gray RAL 7035
1.73″x19.02″x6.50″
M4919125
Supply 1U x 19" front panel, two handles, top cover, base panel, rear panel, M3 x 8 mm (x6), M3 x 8 mm (x6), M4 nut and washer (x4). Supplied assembled.
M4919125
VERSAMET 19" 1Ux10.43"Light gray RAL 7035
1.73″x19.02″x10.43″
M5619225
Supply 19" front bezel, top cover, base panel, rear panel, M4 x 16 mm (x4), M3 x 8 mm (x6), M3 x 8 mm (x6) and M3 x 8 mm (x4). Supplied fully assembled.
M5619225
UNIMET 19" 2Ux11.02"Light gray/window gray RAL 7035/7040
3.46″x19.00″x11.02″
M5619235
Supply 19" front bezel, top cover, base panel, rear panel, M4 x 16 mm (x4), M3 x 8 mm (x6), M3 x 8 mm (x6) and M3 x 8 mm (x4). Supplied fully assembled.
M5619235
UNIMET 19" 2Ux14.96"Light gray/window gray RAL 7035/7040
3.46″x19.00″x14.96″
M5619325
Supply 19" front bezel, top cover, base panel, rear panel, M4 x 16 mm (x4), M3 x 8 mm (x6), M3 x 8 mm (x6) and M3 x 8 mm (x4). Supplied fully assembled.
M5619325
UNIMET 19" 3Ux11.02"Light gray/window gray RAL 7035/7040
5.22″x19.00″x11.02″
M5619335
Supply 19" front bezel, top cover, base panel, rear panel, M4 x 16 mm (x4), M3 x 8 mm (x6), M3 x 8 mm (x6) and M3 x 8 mm (x4). Supplied fully assembled.
M5619335
UNIMET 19" 3Ux14.96"Light gray/window gray RAL 7035/7040
5.22″x19.00″x14.96″
M5623005
Version Without handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.
M5623005
UNIMET 1Light gray/window gray RAL 7035/7040
9.06″x7.48″x1.97″
M5623015
Version Without handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4). Supplied assembled.
M5623015
UNIMET-PLUS 1Light gray/window gray RAL 7035/7040
9.06″x7.60″x1.97″
M5623025
Version With handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.
M5623025
UNIMET 1HLight gray/window gray RAL 7035/7040
9.06″x7.48″x1.97″
M5623035
Version With handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4). Supplied assembled.
M5623035
UNIMET-PLUS 1HLight gray/window gray RAL 7035/7040
9.06″x7.60″x1.97″
M5623105
Version Without handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4), M3 x 8 mm (x4). Supplied assembled.
M5623105
UNIMET 2Light gray/window gray RAL 7035/7040
9.06″x7.48″x3.35″
M5623115
Version Without handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.
M5623115
UNIMET-PLUS 2Light gray/window gray RAL 7035/7040
9.06″x7.60″x3.35″
M5623125
Version With handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.
M5623125
UNIMET 2HLight gray/window gray RAL 7035/7040
9.06″x7.48″x3.35″
M5623135
Version With handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.
M5623135
UNIMET-PLUS 2HLight gray/window gray RAL 7035/7040
9.06″x7.60″x3.35″
M5625105
Version Without handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4), M3 x 8 mm (x4). Supplied assembled.
M5625105
UNIMET 3Light gray/window gray RAL 7035/7040
9.84″x10.24″x3.35″
M5625115
Version Without handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.
M5625115
UNIMET-PLUS 3Light gray/window gray RAL 7035/7040
9.84″x10.35″x3.35″
M5625125
Version With handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.
M5625125
UNIMET 3HLight gray/window gray RAL 7035/7040
9.84″x10.24″x3.35″
M5625135
Version With handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.
M5625135
UNIMET-PLUS 3HLight gray/window gray RAL 7035/7040
9.84″x10.35″x3.35″
M5625305
Version Without handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4), M3 x 8 mm (x4). Supplied assembled.
M5625305
UNIMET 5Light gray/window gray RAL 7035/7040
9.84″x10.24″x5.91″
M5625315
Version Without handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.
M5625315
UNIMET-PLUS 5Light gray/window gray RAL 7035/7040
9.84″x10.35″x5.91″
M5625325
Version With handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.
M5625325
UNIMET 5HLight gray/window gray RAL 7035/7040
9.84″x10.24″x5.91″
M5625335
Version With handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.
M5625335
UNIMET-PLUS 5HLight gray/window gray RAL 7035/7040
9.84″x10.35″x5.91″
M5635205
Version Without handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4), M3 x 8 mm (x4). Supplied assembled.
M5635205
UNIMET 4Light gray/window gray RAL 7035/7040
13.78″x10.24″x4.72″
M5635215
Version Without handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.
M5635215
UNIMET-PLUS 4Light gray/window gray RAL 7035/7040
13.78″x10.35″x4.72″
M5635225
Version With handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.
M5635225
UNIMET 4HLight gray/window gray RAL 7035/7040
13.78″x10.24″x4.72″
M5635235
Version With handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.
M5635235
UNIMET-PLUS 4HLight gray/window gray RAL 7035/7040
13.78″x10.35″x4.72″
M5635305
Version Without handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4), M3 x 8 mm (x4). Supplied assembled.
M5635305
UNIMET 6Light gray/window gray RAL 7035/7040
13.78″x10.24″x5.91″
M5635315
Version Without handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.
M5635315
UNIMET-PLUS 6Light gray/window gray RAL 7035/7040
13.78″x10.35″x5.91″
M5635325
Version With handle/bail arm
Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.
M5635325
UNIMET 6HLight gray/window gray RAL 7035/7040
13.78″x10.24″x5.91″
M5635335
Version With handle/bail arm
Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.
M5635335
UNIMET-PLUS 6HLight gray/window gray RAL 7035/7040
13.78″x10.35″x5.91″
RoHS compliant
Catalog Pages
- Enclosure feet catalog (English) 2,514 KB
- Tilt feet load tests report (TÜV SÜD) 809 KB
- Catálogo Pies De Caja (Español) 2,589 KB
3D Models
- M5600045.stp 236 KB
- M5600045.x_t 214 KB
- M5600045.sat 238 KB
(METCASE product)
